Probe Technical Data
Mechanical
MINIMUM CENTERS: .031 (.79)
MAX TRAVEL: .0.060 (1.52)
OPERATING TRAVEL: .056 (1.42)
OPERATING LIFE: 200,000 cycles
Electrical
Consult Factory
Material and Finishes
PLUNGER: Heat treated beryllium copper
or steel hardened to 55 - 60RC, 24 Kt gold
plated over nickel.
BARREL: Gold clad nickel silver
SPRING: 24 Kt gold plate
Spring Force +/- 20% oz. (grams)
| Spring Type |
Preload |
Operating Position |
| -0 |
.15 (4.2) |
.67 (18.8) |
OPTIONAL 120 DEG. SELF-CLEANING 4-PT CROWN
HEAD STYLE
CAN BE UTILIZED WITH SMALLER OR LARGER THAN NOMINAL
SOLDER BALLS.
PN 08-1-024-280-120 |
 |
|
