| LUTHER & MAELZER BARE BOARD TEST PINS |
SERIES LMP
|
| The pins below are used in Luther & Maelzer bare board test systems. |
Materials and Finishes MATERIAL: Heat treated beryllium copper FINISH: 24 Kt gold plate over hard electroless nickel |
 |
|
Pin style for Series LMP78-102
|
The straight pins shown below are a direct replacement for the LMP78-102
step pins shown left. |
 |
 |
 |
 |
 |
 |
 |
 |
The LMP78-106B90-BP is a replacement for LMP78-106B90 series as shown left. This part is a two-piece steel pin with a berlyllium copper head for single-density grid arrays. | |
 |
 |
|
|
 |
 |
The LMP78-121E-BP is a replacement for LMP78-121E-G1 shown left. This part is a two-piece steel pin with a beryllium copper head for double-density grid arrays. | |
 |
 |
 |
 |
 |
| The LMP78-105 barrel, combined with any of the tips listed below, are for use with Luther & Maelzer bare board tests systems. | Materials and Finishes MATERIAL: Heat treated beryllium copper, 24 Kt gold plate over gard electroless nickel TIPS: Heat treated beryllium copper, 24 Kt gold plate over gard electroless nickel |
 |
 |
 |
 |
 |
 |
 |
 |
 |
